Specifications:
Model
FT-ANT24D15Y-018
Electrical Specifications
Type
Directional Antenna
Frequency range 【MHz】
2400-2485
Band width 【MHz】
85
Gain 【dBi】
15
Beam width
E—Plane
40°
H—Plane
43°
Front to Back Ratio
≥15dB
VSWR
≤1.5
Polarization
Vertical
Max power 【W】
150
Impedance 【Ω】
50
Lightning protection
Direct Ground
Mechanical Specifications
Cable length 【mm】
260
Connector
N female
Temperature
-40~60℃
Dimensions 【mm】
Φ70x650
Weight 【kg】
1.3
